Hose ID | Hose O.D. | Working Pressure | Min. Burst | Min. Bend | Length | Weight | ||||||
In. | mm | In. | mm | psi | MPa | psi | MPa | In. | mm | m | kg/m | lb/ft |
3/4 | 19.0 | 1.22 | 31.0 | 6090 | 42.0 | 27840 | 168.0 | 11.0 | 280.0 | 20/40/60 | 1.58 | 1.07 |
1 | 25.4 | 1.48 | 37.6 | 5510 | 38.0 | 22040 | 152.0 | 13.4 | 340.0 | 20/40/60 | 2.01 | 1.36 |
1 1/4 | 31.8 | 1.79 | 45.4 | 4713 | 32.5 | 18850 | 130.0 | 18.1 | 460.0 | 20/40/60 | 2.68 | 1.81 |
1 1/2 | 38.1 | 2.06 | 52.4 | 4200 | 29.0 | 16800 | 116.0 | 22.0 | 560.0 | 20/40/60 | 3.30 | 2.23 |
2 | 50.8 | 2.63 | 66.8 | 3625 | 25.0 | 14500 | 100.0 | 27.6 | 700.0 | 20/40/60 | 4.37 | 2.95 |
