Oil hose

Features

Internal hose：Synthetic rubber, extruded whole without joints, of uniform thickness.
Covering：Anti-abrasive synthetic rubber, resistant to oils, fuels and atmospheric conditions
Reinforcement：1 textile braids.
Working Pressure：20 Bar /290 Psi
Operating temperature：From-40 to +100°C (intermittent 120°C), from-40 to +70°C for water based fluids, from 0 to +70°C hot air. Prolonged operation at extreme temperatures will reduce hoses life.
Recommended fluid：Oil Hose is suitable for oil delivery

Consult now

Technical Specifications

Inside Diameter		Outside Diameter	Working Pressure		Burst Pressure		Nominal Weight	Length
inch	mm	mm	bar	psi	bar	psi	kg/m	m
1/4	6	13	20	300	60	900	0.15	50 / 100
5/16	8	15	20	300	60	900	0.21	50 / 100
3/8	10	18	20	300	60	900	0.27	50 / 100
1/2	13	21	20	300	60	900	0.35	50 / 100
5/8	16	25	20	300	60	900	0.50	50
3/4	19	29	20	300	60	900	0.61	50
1	25	36	20	300	60	900	0.83	50
