尺寸 | 管内径 | 管外径 | 工作压力 | 爆破压力 | 弯曲半径 | 长度 | 重量 | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
In. | mm | Min | Max | Min | Max | Bar | Psi | Bar | Psi | mm | m | kg/m |
3/16 | 5 | 4.5 | 5.4 | 11.9 | 13.5 | 105 | 1520 | 420 | 6090 | 75 | 50 | 0.16 |
1/4 | 6.3 | 6.1 | 7.0 | 13.5 | 15.1 | 87 | 1260 | 348 | 5046 | 75 | 50 | 0.19 |
5/16 | 8 | 7.6 | 8.5 | 16.7 | 18.3 | 84 | 1220 | 336 | 4870 | 100 | 50 | 0.25 |
3/8 | 10 | 9.2 | 10.1 | 18.3 | 19.8 | 78 | 1130 | 312 | 4520 | 100 | 50 | 0.28 |
13/32 | 11 | 10.3 | 11.1 | 20.0 | 21.0 | 74 | 1070 | 296 | 4290 | 100 | 50 | 0.30 |
1/2 | 12.5 | 12.4 | 13.5 | 23.0 | 24.6 | 70 | 1020 | 280 | 4060 | 125 | 50 | 0.39 |
5/8 | 16 | 15.6 | 16.7 | 26.2 | 27.8 | 61 | 880 | 244 | 3538 | 140 | 50 | 0.45 |
3/4 | 19 | 18.7 | 19.8 | 31.0 | 32.5 | 52 | 750 | 208 | 3016 | 150 | 50 | 0.64 |
1 | 25 | 25.1 | 26.2 | 36.9 | 39.3 | 39 | 570 | 156 | 2262 | 205 | 50 | 0.77 |
1 1/4 | 31.5 | 31.4 | 32.9 | 42.9 | 46.0 | 26 | 380 | 104 | 1508 | 250 | 40/50 | 0.97 |
1 1/2 | 38 | 37.7 | 38.5 | 50.0 | 52.0 | 24 | 350 | 96 | 1392 | 300 | 40/50 | 1.12 |
