管内径 | 管外径 | 工作压力 | 最小爆破压力 | 最小弯曲半径 | 长度 | 重量 | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
In. | mm | In. | mm | psi | MPa | psi | MPa | In. | mm | m | kg/m | lb/ft |
1/4 | 6.4 | 0.50 | 12.7 | 3045 | 21.0 | 12180 | 84.0 | 1.5 | 38.1 | 50/100 | 0.21 | 0.14 |
5/16 | 7.9 | 0.56 | 14.2 | 3045 | 21.0 | 12180 | 84.0 | 1.8 | 45.7 | 50/100 | 0.25 | 0.17 |
3/8 | 9.5 | 0.63 | 16.0 | 3045 | 21.0 | 12180 | 84.0 | 2.0 | 50.8 | 50/100 | 0.31 | 0.21 |
1/2 | 12.7 | 0.80 | 20.4 | 3045 | 21.0 | 12180 | 84.0 | 2.8 | 71.1 | 50/100 | 0.57 | 0.39 |
5/8 | 15.9 | 0.97 | 24.6 | 3045 | 21.0 | 12180 | 84.0 | 3.0 | 76.2 | 50/100 | 0.75 | 0.51 |
3/4 | 19.0 | 1.09 | 27.8 | 3045 | 21.0 | 12180 | 84.0 | 3.8 | 96.5 | 50 | 0.92 | 0.62 |
1 | 25.4 | 1.39 | 35.4 | 3045 | 21.0 | 12180 | 84.0 | 4.5 | 114.3 | 50 | 1.35 | 0.91 |
