管内径 | 管外径 | 工作压力 | 最小爆破压力 | 最小弯曲半径 | 长度 | 重量 | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
In. | mm | In. | mm | psi | MPa | psi | MPa | In. | mm | m | kg/m | lb/ft |
1/4 | 6.4 | 0.53 | 13.5 | 5800 | 40.0 | 23200 | 160 | 1.5 | 38.1 | 50/100 | 0.31 | 0.21 |
5/16 | 7.9 | 0.60 | 15.3 | 5075 | 35.0 | 20300 | 140 | 1.8 | 45.7 | 50/100 | 0.37 | 0.25 |
3/8 | 9.5 | 0.71 | 18.0 | 4785 | 33.0 | 19140 | 132 | 2.0 | 50.8 | 50/100 | 0.47 | 0.32 |
1/2 | 12.7 | 0.83 | 21.1 | 3990 | 27.5 | 15950 | 110 | 2.8 | 71.1 | 50/100 | 0.60 | 0.41 |
5/8 | 15.9 | 0.97 | 24.7 | 3625 | 25.0 | 14500 | 100 | 3.0 | 76.2 | 50/100 | 0.73 | 0.49 |
3/4 | 19.0 | 1.10 | 28.0 | 3120 | 21.5 | 12470 | 86 | 3.8 | 96.5 | 50 | 0.87 | 0.59 |
1 | 25.4 | 1.40 | 35.6 | 2395 | 16.5 | 9570 | 66 | 4.5 | 114.3 | 50 | 1.38 | 0.93 |
1 1/4 | 31.8 | 1.71 | 43.5 | 1815 | 12.5 | 7250 | 50 | 5.9 | 150.0 | 50 | 1.78 | 1.20 |
