英制尺寸
| 公制尺寸 | 工作压力
| 爆破压力
| 重量
| ||
|---|---|---|---|---|---|---|
内径 | 壁厚 | 长度 | ||||
Inch | mm | Thickness | M/roll | Mpa | Mpa | Kg/m |
3/8 | Φ10 | 2.8-3.0 | 100 | 0.5 | 1.5 | 0.2 |
1/2 | Φ13 | 2.8-3.0 | 100 | 0.5 | 1.5 | 0.23 |
5/8 | Φ16 | 2.3-2.8 | 100 | 0.5 | 1.5 | 0.25 |
3/4 | Φ19 | 2.5-2.8 | 50 | 0.5 | 1.5 | 0.3 |
3/4 | Φ19 | 3.6-3.8 | 50 | 0.5 | 1.5 | 0.4 |
1 | Φ25 | 1.5-1.7 | 50 | 0.35 | 1.05 | 0.25 |
1 | Φ25 | 1.7-1.8 | 50 | 0.4 | 1.2 | 0.3 |
1 | Φ25 | 2.6-2.8 | 50 | 0.45 | 1.35 | 0.4 |
1-1/4 | Φ32 | 2.3-2.5 | 50 | 0.3 | 0.9 | 0.5 |
1-1/4 | Φ32 | 3.2-3.5 | 50 | 0.4 | 1.2 | 0.7 |
1-3/8 | Φ34 | 2.9-3.0 | 50 | 0.3 | 0.9 | 0.6 |
1-1/2 | Φ38 | 2.2-2.3 | 50 | 0.2 | 0.6 | 0.5 |
1-1/2 | Φ38 | 3.5-3.8 | 50 | 0.35 | 1.05 | 0.8 |
1-1/2 | Φ38 | 4.2-4.5 | 50 | 0.45 | 1.35 | 0.1 |
| Φ40 | 3.0-3.5 | 50 | 0.25 | 0.75 | 0.7 |
1-3/4 | Φ45 | 3.0-3.3 | 50 | 0.25 | 0.75 | 0.8 |
1-3/4 | Φ45 | 3.6-3.7 | 50 | 0.35 | 1.05 | 1.0 |
2 | Φ50 | 2.5-2.8 | 50 | 0.2 | 0.6 | 0.8 |
2 | Φ50 | 3.2-3.3 | 50 | 0.25 | 0.75 | 1.0 |
2 | Φ50 | 3.7-3.8 | 50 | 0.35 | 1.05 | 1.2 |
2 | Φ50 | 4.8-4.9 | 50 | 0.4 | 1.2 | 1.4 |
2-3/8 | Φ58 | 3.8-4.0 | 40 | 0.25 | 0.75 | 1.2 |
2-3/8 | Φ58 | 4.2-4.5 | 40 | 0.25 | 0.75 | 1.4 |
2-1/2 | Φ64 | 2.8-3.1 | 40 | 0.12 | 0.36 | 1.2 |
2-1/2 | Φ64 | 3.5-3.7 | 40 | 0.18 | 0.54 | 1.6 |
2-1/2 | Φ64 | 5.0-5.5 | 40 | 0.25 | 0.75 | 2.0 |
3 | Φ75 | 3.8-4.0 | 40 | 0.18 | 0.54 | 1.8 |
3 | Φ75 | 4.3-4.7 | 40 | 0.2 | 0.6 | 2.0 |
3 | Φ75 | 5.3-5.5 | 40 | 0.3 | 0.9 | 2.5 |
3-1/2 | Φ89 | 3.8-4.2 | 30 | 0.15 | 0.45 | 2.5 |
3-1/2 | Φ89 | 5.5-6.0 | 30 | 0.2 | 0.6 | 3.0 |
4 | Φ102 | 4.2-4.3 | 30 | 0.1 | 0.3 | 2.6 |
4 | Φ102 | 5.0-5.3 | 30 | 0.15 | 0.45 | 3.0 |
4-1/2 | Φ110 | 5.0-5.2 | 20 | 0.3 | 0.9 | 4.5 |
5 | Φ127 | 5.0-5.4 | 20 | 0.3 | 0.9 | 5.0 |
6 | Φ152 | 6.0-6.3 | 20 | 0.3 | 0.9 | 6.0 |
