管内径 | 管外径 | 壁厚 | 工作压力 | 爆破压力 | 最小弯曲半径 | 长度 | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
In. | mm | In. | mm | In. | mm | psi | Bar | psi | Bar | In. | mm | kg/m |
1/8 | 3.5 | 0.260 | 6.6 | 0.039 | 1.00 | 3444 | 238 | 13775 | 950 | 0.472 | 12 | 0.07 |
3/16 | 5.0 | 0.307 | 7.8 | 0.033 | 0.85 | 3009 | 208 | 12035 | 830 | 0.591 | 15 | 0.08 |
1/4 | 6.5 | 0.370 | 9.4 | 0.033 | 0.85 | 2719 | 188 | 10875 | 750 | 0.591 | 15 | 0.10 |
5/16 | 8.0 | 0.445 | 11.3 | 0.033 | 0.85 | 2248 | 155 | 8990 | 620 | 0.984 | 25 | 0.14 |
3/8 | 10.0 | 0.524 | 13.3 | 0.033 | 0.85 | 1958 | 138 | 7830 | 550 | 1.378 | 35 | 0.17 |
13/32 | 10.3 | 0.535 | 13.6 | 0.033 | 0.85 | 1885 | 130 | 7540 | 520 | 1.575 | 40 | 0.17 |
1/2 | 13.0 | 0.650 | 16.5 | 0.039 | 1.00 | 2272 | 125 | 6818 | 500 | 1.811 | 46 | 0.24 |
5/8 | 16.0 | 0.764 | 19.4 | 0.039 | 1.00 | 1233 | 85 | 4930 | 340 | 5.906 | 150 | 0.27 |
3/4 | 19.0 | 0.906 | 23.0 | 0.047 | 1.20 | 1051 | 73 | 4205 | 290 | 6.693 | 170 | 0.37 |
7/8 | 22.2 | 1.031 | 26.2 | 0.047 | 1.20 | 870 | 60 | 3480 | 240 | 9.449 | 240 | 0.42 |
1 | 25.4 | 1.181 | 30.0 | 0.059 | 1.50 | 870 | 60 | 3480 | 240 | 11.811 | 300 | 0.53 |
